Description
SPECS
Thermal Module
- Image Sensor: V0x Uncooled Focal Plane Arrays
- Max. Resolution: 256×192
- Frame Rate: 50 Hz
- Pixel Internal: 12μm
- Response Waveband: 8μm to 14μm
- NETD: < 50mK [@25°C, F#=1.0]
- Lens (focal length): 9.7mm
- Detection Range: 970m
- Aperture: F1.0
- Magnification: 1x to 2x [Digital zoom 2x]
- FOV (HxV), Degrees m@100m: 18.1°x13.6° / 31.8mx23.8m
Image Display
- Image Mode: Birdwatching/ Red Hot/ White Hot/ Black Hot/ Rainbow/ Ironbow
- Contrast Adjustment: Adjustable contrast from 0 to 100 by slider control
- Brightness Adjustment: Adjustable contrast from 0 to 100 by slider control
System
- Record Video: Yes
- Capture Snapshot: Yes
- PIP: Yes
- Digital Magnetic Compass: Yes
- Hot Track: Yes
System
- Power Supply: USB Type-C interface
- Power Consumption: 360mW
- Working Temperature: -10°C TO 50°C
- Dimension: 26.6mm x 26.6mm x 27.2mm
- Weight: 26g
- Protection Level: IP40
