Main

• Max. Resolution: 3840 × 2160
• Frame Rate: 50 Hz
• Lens (Focal Length): 50 mm, F1.2 to 2.5 Adjustable Aperture
• Detection Range: Day: 1000 m
• Min. Focusing Distance: 10 m
• Magnification: 3.5x to 28.0x (8x). Support Continuous Zooming
• Field of View: 8.8° × 5.0°/15.3 m × 8.6 m @100 m

Image Display

• Display: 1920 × 1080, 0.49 inch, OLED
• Image Mode: Day, Night
• Exit Pupil: 6 mm
• Eye Relief: 55 mm
• Diopter (Range): -5 D to 5 D

System

• Record Video: On-board Video Recording
• Record Video Resolution: 1920 × 1080
• Capture Snapshot: Yes
• Audio Recording: Yes
• Recoil-activation Recording: Yes
• Standby Mode: Yes
• Storage: Built-in EMMC (64 GB)
• PIP: Yes
• Freeze Zeroing: Yes
• Distance Measurement: NA
• Zeroing Profiles: 5
• Max. Recoil: 1000 g/0.4 ms
• Hotspot: Yes
• Ballistic Calculation: Yes

Power Supply

• Battery Type: Two Rechargeable Lithium Batteries (Internal), One Replaceable and Rechargeable 18650 Battery (External)
• Battery Operating Time: 11 hours of Continuous Running (@25°C, Hotspot off)
• Power Supply: 5 VDC/2 A, USB Type-C Interface

General

• Mounting: Standard 30 mm
• Protection Level: IP67
• Working Temperature: -30°C to 55°C (-22°F to 131°F)
• Dimension: 439.8 mm × 89.2 mm × 84.0 mm
• Weight: 1176 g without External Battery

Laser Rangefinder

• Safety Class for Laser: Class1
• Wavelength: 905 nm
• Max. Measuring Range: 1000 m
• Measurement Accuracy: ±1 m
• Min. Measuring Range: 10 m
